6 Layer Blue Oil Immersion Gold High Frequency Circuit Board for Industrial Control
Product Details:
| Place of Origin: | China |
| Brand Name: | xingqiang |
| Certification: | ROHS, CE |
| Model Number: | KAZD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | NA |
| Delivery Time: | 15-20 work days |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 3000㎡ |
|
Detail Information |
|||
| Materials: | FR-4 | Number Of Layers: | 3 |
|---|---|---|---|
| Surface Finished: | Immersion Gold | Copper Thicknes: | 1/1/1/1/1/1oz |
| Impedance Control: | Yes | Layer Count: | 1-30 Layers |
| Silk Screen: | White | Blind/Buried Vias: | Available |
| Usage: | Communication PCB | Layer: | 4 Layers |
| Min. Line Width/Spacing: | 3mil | ||
| Highlight: | Immersion Gold High Frequency Circuit Board,6 Layer High Frequency Circuit Board,Industrial Control PCB 6 Layer |
||
Product Description
6-layer blue oil electric gold high-frequency industrial control version
product Description:
The 6-Layer Blue Solder Mask Immersion Gold Industrial Control PCB is a high-performance printed circuit board specifically engineered for industrial control applications. As a critical component in industrial automation systems, it integrates seamlessly into industrial machinery, automation equipment, and control modules, serving as the core platform for electrical signal transmission, control command execution, and stable power distribution. This industrial control PCB features a specialized 6-layer architecture, complemented by blue solder mask coating and immersion gold finishing—key enhancements that deliver multiple performance advantages. The immersion gold surface treatment ensures superior electrical conductivity, excellent oxidation resistance, and reliable solderability, while the blue solder mask provides robust insulation protection and enhances environmental resilience against moisture, dust, and chemical exposure. Designed to meet stringent industrial standards, the PCB incorporates advanced engineering considerations including optimized power management, signal integrity preservation, and electromagnetic interference (EMI) mitigation. Its multilayer structure enables high-density wiring configurations, facilitating complex circuit integration while minimizing signal crosstalk and spatial footprint. From material selection—utilizing high-temperature-resistant glass fiber-reinforced epoxy substrates—to precision manufacturing processes, every aspect is engineered to guarantee exceptional reliability, durability, and operational stability in harsh industrial environments characterized by extreme temperatures, high humidity, and mechanical stress.
product Features:
- 6-Layer Multilayer Architecture: Adopts a precision-engineered 6-layer structure to support high-density wiring, enabling complex circuit integration while minimizing signal crosstalk and optimizing spatial utilization for industrial control systems.
- Blue Solder Mask Coating: Features a specialized blue solder mask that provides robust electrical insulation, enhances mechanical protection, and improves resistance to moisture, dust, and chemical contaminants in harsh industrial environments.
- Immersion Gold Finishing: Incorporates immersion gold surface treatment to deliver superior electrical conductivity, exceptional oxidation resistance, and reliable solderability, ensuring long-term connection stability and reducing maintenance requirements.
- Industrial-Grade Reliability: Engineered with high-performance glass fiber-reinforced epoxy substrates, ensuring stable operation under extreme conditions including wide temperature fluctuations (-40°C to 125°C), high humidity, and chemical exposure.
- Enhanced Signal Integrity: Optimized layout design prioritizes power management and signal integrity, with built-in measures for electromagnetic interference (EMI) mitigation to ensure accurate transmission of control signals and data.
- Durable Construction: Manufactured to stringent industrial standards, combining advanced material selection and precision manufacturing processes to achieve enhanced durability, extended service life, and resistance to mechanical stress in industrial operation.
