Sinking Gold High Density PCB 12 Layers , Multiple Layers HD Printed Circuit Board
Product Details:
| Brand Name: | High Density PCB |
| Certification: | ROHS, CE |
| Model Number: | Varies by goods condition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 square meters |
|---|---|
| Price: | NA |
| Delivery Time: | 15-16 work days |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 3000㎡ |
|
Detail Information |
|||
| Surface Finish: | HASL, ENIG, OSP | Count: | 8 Layer |
|---|---|---|---|
| Testing Service: | 100% Testing | Cooper Thickness: | 2oz Out Layer , 1oz Inner Layer |
| Min. Hole Size: | 0.1mm | Layer: | 12L |
| Board Size: | Customized | Min. Line Width/Spacing: | 0.075mm/0.075mm |
| Highlight: | Sinking Gold High Density PCB,Multiple Layers HD Printed Circuit Board |
||
Product Description
Product Description:
The High Density PCB is a cutting-edge circuit board specifically designed for demanding applications in the automotive electronics industry. With a superior construction and advanced features, this PCB is ideal for projects that require high performance and reliability.
Key Product Attributes:
- Copper Thickness: The High Density PCB boasts a copper thickness of 2oz on the outer layers and 1oz on the inner layers. This design ensures excellent conductivity and heat dissipation, making it suitable for high-power applications.
- Layer Count: This PCB features 8 layers, allowing for complex circuitry and improved signal integrity. The multiple layers also enable efficient routing of signals and power, reducing electromagnetic interference.
- Thickness: With a thickness of 1.2mm, the High Density PCB strikes the perfect balance between durability and flexibility. This thickness makes it suitable for compact designs while maintaining structural integrity.
- Minimum Via Diameter: The PCB supports a minimum via diameter of 0.2mm, facilitating the implementation of staggered vias for optimized signal routing and signal integrity (SI).
- Surface Finish: The High Density PCB offers multiple surface finish options including HASL, ENIG, OSP. These finishes provide varying levels of solderability, corrosion resistance, and conductivity to meet different project requirements.
Staggered Vias are a critical feature of the High Density PCB, allowing for precise signal routing and improved SI. By strategically placing vias in a staggered configuration, signal interference and crosstalk are minimized, resulting in enhanced signal quality and reliability.
Automotive electronics demand robust and reliable components, and the High Density PCB delivers on these requirements. Whether used in engine control units, infotainment systems, or advanced driver-assistance systems, this PCB ensures consistent performance under challenging conditions.
Signal integrity is paramount in automotive electronics, where data accuracy and reliability are crucial for vehicle operation and safety. The High Density PCB's advanced design and material choices help maintain signal integrity by minimizing signal loss, reflections, and distortions, ensuring seamless communication between components.
In conclusion, the High Density PCB is a top-of-the-line circuit board tailored for high-density and high-performance applications in automotive electronics. With its exceptional features, including staggered vias, optimal copper thickness, and multiple surface finish options, this PCB is the perfect choice for projects that demand reliability, signal integrity, and superior performance.
Features:
- Product Name: High Density PCB
- Board Size: Customized
- Min. Line Width/Spacing: 0.075mm/0.075mm
- Impedance Control: ±10%
- Minimum Via Dia: 0.2mm
- Surface Finish: HASL, ENIG, OSP
Technical Parameters:
| Testing Service | 100% Testing |
| Count | 8 Layer |
| Layer Count | 1-30 |
| Layer | 12L |
| Board Size | Customized |
| Min. Hole Size | 0.1mm |
| Min. Line Width/Spacing | 0.075mm/0.075mm |
| Min. Solder Mask Clearance | 0.1mm |
| Copper Thickness | 2oz Out Layer , 1oz Inner Layer |
| Board Thickness | 1.2mm |
Customization:
Customize your High Density PCB product to fit your specific needs with our Product Customization Services:
- Brand Name: High Density PCB
- Place Of Origin: China
- Surface Finish: HASL, ENIG, OSP
- Cooper Thickness: 2oz Out Layer, 1oz Inner Layer
- Min. Hole Size: 0.1mm
- Min. Order Quantity: 5㎡
- Thickness: 1.2mm
Enhance your High Density PCB for applications in smartphones, with features like Stacked Vias for improved Signal Integrity (SI).
Summary of HDPCB Applications by Sector
| Sector | Key Applications | Critical HDPCB Features Used |
|---|---|---|
| Consumer Electronics | Smartphones, laptops, wearables | Fine traces, microvias, flexible-rigid hybrids |
| Data Centers/Cloud | Server motherboards, AI accelerators, networking gear | High-layer counts, controlled impedance, thermal vias |
| Medical Devices | Implants, imaging equipment, portable monitors | Miniaturization, biocompatible finishes, radiation resistance |
| Automotive | EV BMS, ADAS, IVI systems | High-voltage tolerance, vibration resistance, thermal management |
| Aerospace & Defense | Avionics, military drones, satellites | Radiation hardening, extreme temperature resistance, durability |
