Category Connection: Rigid Flex PCB
Chat Now Contact Us
Tags:
#Rigid Flexible PCB #Flexible Rigid PCB #Rigid Flex Printed Circuit Board
Brief: Stay tuned as we highlight the most important features and real-use results. In this video, we demonstrate our turnkey flex-rigid PCB manufacturing process, showcasing how we integrate ENIG-finished rigid areas with durable polyimide flex circuits. You'll see how complex components like fine-pitch BGA chips and high-speed connectors are assembled, and learn about our customizable layer counts, via types, and stiffener frames that improve reliability in compact environments.
Related Product Features:
  • Custom high-performance flex-rigid PCBs with integrated component assembly for complex applications.
  • ENIG-finished rigid FR-4 areas combined with durable polyimide flex circuits for enhanced durability.
  • Supports integration of fine-pitch BGA chips, high-speed connectors, and EMI filters directly on the board.
  • Fully customizable layer counts from 1 to 30+ layers with various pad sizes and via types.
  • Space-saving design that eliminates connectors and cables, reducing assembly size and weight.
  • Enhanced reliability with fewer interconnections, lower failure risk, and improved signal integrity.
  • Superior durability resistant to vibration, shock, and extreme temperatures for harsh environments.
  • RoHS and CE compliant with premium quality certifications including ISO 9001 and IATF 16949.
FAQs:
  • What are the main advantages of using Rigid-Flex PCBs?
    Rigid-Flex PCBs offer space-saving design by eliminating connectors and cables, enhanced reliability with fewer interconnection failures, superior durability against vibration and extreme temperatures, flexible configuration for custom layer counts and materials, high-density interconnect capabilities, and compliance with RoHS and CE standards.
  • What customization options are available for these PCBs?
    You can fully customize layer counts from 1 to over 30 layers, pad sizes, via types including through-hole, blind, and buried vias, stiffener frames, materials such as FR-4 and polyimide flex circuits, bend radius requirements, and surface finishes including ENIG, HASL, and Immersion Tin to meet your specific mechanical and electrical needs.
  • What file preparation is required for custom Rigid-Flex PCB manufacturing?
    Required files include complete Gerber files for all layers, drill files in Excellon format, stack-up drawings showing layer order and materials, PCB outline drawings, component placement files, bill of materials for assembly, and special instructions for impedance control, flex bend requirements, surface finish, and test points.
