6 Layer Flexible Rigid Circuit Boards and Tested by Flying Probe for Optimum Performance
Product Details:
| Brand Name: | Xingqiang |
| Certification: | ISO 9001 / RoHS /UL / IATF 16949 (automotive) |
| Model Number: | Varies By Goods Condition |
Payment & Shipping Terms:
| Minimum Order Quantity: | Sample,1 Pc(5 Square Meters) |
|---|---|
| Price: | Based on Gerber Files |
| Delivery Time: | NA |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 100000㎡/Month |
|
Detail Information |
|||
| Printed Circuit Board: | Flexible Rigid Circuit Board | Surface Finish: | ENIG |
|---|---|---|---|
| Copper Overall: | 0.5-5oz | Board Size: | Customized |
| Layer Struction: | 1-30L Or 30L+ | Material: | High Tg FR-4+PI |
| SMT Tech: | SMD, BGA, DIP, Etc. | Pcb Test: | Flying Probe Test, E-test, Etc. |
| Quote Requirement: | Gerber File And Bom List | Customized Thickness: | 1.6/1.2/1.0/0.8mm Or Customized |
| Highlight: | 6 layer rigid flex PCB,flying probe tested circuit boards,flexible rigid PCB optimum performance |
||
Product Description
What is Flexible Rigid Circuit Boards?:
A Flex-Rigid PCB, also known as Rigid-Flex Printed Circuit Board, is a type of circuit board that combines both flexible and rigid board technologies into a single design. This unique construction allows for increased design flexibility and reliability, making it an ideal choice for applications where space is limited or where the board needs to conform to a specific shape.Our Rigid Flex PCB product offers a variety of features and specifications to meet the needs of our customers.The PCB size is fully customizable, allowing for a tailored solution that fits the specific requirements of each project.When requesting a quote for our Flex-Rigid PCB product, customers are required to provide Gerber Files and a Bill of Materials (BoM) list. These essential documents ensure that the manufacturing process is accurate and efficient, resulting in high-quality boards that meet the desired specifications.
Technical Parameters:
| Impedance Control | ±10% Or 5% |
| Pth | ±0.075mm |
| Layer | 2/4/6/8/10L |
| Thickness | 1.6/1.2/1.0/0.8mm or customized |
| SMT Technology | SMD, BGA, DIP, Etc. |
| Min.line Width | 3Mil |
| Max Board Size | 528*600mm |
| Min.hole Size | 0.1mm |
| Copper Overall | 0.5-5oz |
| Routing | +/-0.1mm |
Applications:
1. Automotive Industry: Xingqiang Rigid-Flex Circuit Boards are ideal for automotive applications due to their ability to withstand harsh environmental conditions, vibrations, and mechanical stress. They are commonly used in engine control units, airbag systems, infotainment systems, and more.
2. Medical Devices: With ROHS and CE certifications, Xingqiang Flex-Rigid PCBs are suitable for medical devices where reliability and precision are critical. They are commonly used in patient monitoring systems, diagnostic equipment, and medical imaging devices.
3. Aerospace and Defense: The rugged construction of Xingqiang Rigid-Flex Circuit Boards makes them suitable for aerospace and defense applications. They can be found in avionics systems, UAVs, missile guidance systems, and communication equipment.
4. Industrial Automation: Xingqiang Rigid-Flex PCBs are well-suited for industrial automation applications where space constraints and complex designs are common. They are used in PLCs, robotics, control systems, and sensor modules.
5. Consumer Electronics: Xingqiang Rigid-Flex Printed Circuit Boards are increasingly being used in consumer electronics such as smartphones, wearables, and IoT devices. Their compact size and high reliability make them ideal for compact electronic gadgets.
