8 Layer Rigid Printed Circuit Board PCB 1.2mm Thickness For Automotive Electronics
Product Details:
| Brand Name: | Xingqiang |
| Certification: | ROHS, CE |
| Model Number: | Varies by goods condition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 square meters |
|---|---|
| Price: | NA |
| Delivery Time: | 14-15 work days |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 3000㎡ |
|
Detail Information |
|||
| Standard: | IPC-A-610E | Surface Finishing: | HASL,OSP, ENIG |
|---|---|---|---|
| No Of Layers: | 2 | Pcb Thickness: | 1.2mm |
| Copper: | 2/1/1/2 OZ | Soder Mask Color: | Green/Red/Blue/Black/Yellow/White |
| Copper Thickness: | 0.5oz-6oz | Soldermask: | Green |
| Minimum Line Space: | 3mil (0.075mm) | Materila: | FR4 |
| Highlight: | 8 Layer Rigid Printed Circuit Board,Rigid PCB 1.2mm Thickness,Rigid PCB For Automotive Electronics |
||
Product Description
Product Description
8-layer buried gold HDI thick copper PCB
HDI Thick Copper PCB stands for High-Density Interconnect Thick Copper Printed Circuit Board. This advanced type of circuit board combines two key technologies: High-Density Interconnect (HDI) and Thick Copper. The result is a powerful PCB that is ideal for applications requiring both miniaturization and high power handling.
Product Feature
-
Enhanced Current-Carrying Capacity: The use of thick copper layers (typically 3 oz to 20 oz, compared to the standard 1 oz) significantly reduces the board's electrical resistance. This allows it to handle much larger currents with minimal heat generation, making it perfect for power electronics.
-
Superior Thermal Management: The thick copper acts as a highly effective heatsink, efficiently dissipating heat from critical components. This prevents overheating, improves the reliability of the system, and can extend the lifespan of electronic components.
-
High Component Density: Leveraging HDI technology, these PCBs use advanced features like micro-vias, blind vias, and buried vias. This allows for tighter component placement and denser routing, enabling the creation of smaller, more compact electronic devices without sacrificing performance.
-
Improved Mechanical Strength: The thicker copper layers add physical rigidity and durability to the circuit board, making it more robust and resistant to mechanical stress. This is crucial for products used in harsh environments.
-
Reduced Board Size and Weight: By combining high power capacity with high component density, these boards can replace multiple conventional PCBs, leading to smaller, lighter, and more efficient final products.
Application Scenarios
Due to their unique combination of power handling and miniaturization, HDI Thick Copper PCBs are used in a variety of demanding applications:
-
Automotive Electronics: Power steering systems, engine control units (ECUs), and electric vehicle (EV) charging systems, where high current and high reliability are critical.
-
Industrial Control Systems: High-power motor drives, robotic control systems, and power converters that require robust and compact circuit boards.
-
Renewable Energy: Inverters and power management systems for solar panels and wind turbines.
-
Medical Devices: High-power medical imaging equipment and other portable diagnostic tools that need to be both powerful and compact.
-
Aerospace and Defense: Avionics and power supply modules for military and aerospace systems, where reliability and performance in a small form factor are non-negotiable.
