300mmx100mm Military PCB Board With Yellow Solder Mask Color 1.2mm Thick
Product Details:
| Brand Name: | Military PCB |
| Certification: | ROHS, CE |
| Model Number: | Varies by goods condition |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 square meters |
|---|---|
| Price: | NA |
| Delivery Time: | 14-15 work days |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 3000㎡ |
|
Detail Information |
|||
| Material: | FR4 | Solder Mask Color: | Green, Blue, Black, Red, Yellow, White |
|---|---|---|---|
| Impedance Control: | ±10% | Max. Panel Size: | 528mm X 600mm |
| Copper Weight: | 1-6oz | Min. Line Width/Spacing: | 3 Mil |
| Silkscreen Color: | White, Black, Yellow | Min. Hole Size: | 0.1mm |
| Highlight: | 300mmx100mm Military PCB Board,1.2mm Thick Military PCB Board |
||
Product Description
Product Description:
Military PCB products represent the pinnacle of reliability, durability, and performance in printed circuit board technology. Designed to operate flawlessly in the world's harshest environments and mission-critical scenarios, these PCBs adhere to stringent military standards (MIL-SPEC) and undergo rigorous qualification processes. They form the foundational hardware backbone of advanced defense systems where failure is not an option.Features:
- Product Name: Military PCB
- Impedance Control: ±10%
- Material: High-grade Military Grade Materials
- Certifications: ROHS, CE
- Min. Hole Size: 0.1mm
- Min. Line Width/Spacing: 0.075mm
Technical Parameters:
| Surface Finish | HASL, OSP, ENIG |
| Max. Panel Size | 528mm X 600mm |
| Min. Panel Size | 50mm X 50mm |
| Min. Line Width/Spacing | 3mil (0.075mm) |
| Testing Method | Flying Probe, Fixture Test |
| Silkscreen Color | White, Black, Yellow |
| Certifications | ROHS, CE |
| Min. Hole Size | 0.1mm |
| Solder Mask Color | Green, Blue, Black, Red, Yellow, White |
| Thickness | 1.2mm |
Applications:
The Military PCB product, originating from China, is a high-quality electronic component designed specifically for military applications. Its construction using high-grade military-grade materials ensures durability, making it suitable for a wide range of challenging environments.
One of the key attributes of the Military PCB is its long lifespan, which is crucial for military equipment that needs to operate reliably over extended periods. The use of materials that can withstand extreme temperatures further enhances its suitability for various military applications, from desert operations to high-altitude missions.
Additionally, the Military PCB offers exceptional vibration resistance, a critical feature for military equipment subjected to constant movement and rough handling. This resilience ensures that the PCB remains intact and functional even in the most demanding operational scenarios.
The surface finish options of Immersion Gold, HASL, OSP, and ENIG provide flexibility in meeting specific project requirements. The ±10% impedance control capability ensures signal integrity and reliability, essential for mission-critical communication systems.
Furthermore, the choice of silkscreen colors in white, black, and yellow allows for clear and easy labeling of components, aiding in assembly and maintenance processes. The PCB's thickness range of 0.2-5.0mm caters to diverse application needs, providing options for compact designs or robust constructions.
In summary, the Military PCB product excels in offering a combination of durability, reliability, and adaptability for military electronics applications. Its long lifespan, extreme temperature resistance, and vibration resistance make it a dependable choice for mission-critical operations in challenging environments.
Customization:
Product Customization Services for the Military PCB:
Brand Name: Military PCB
Place Of Origin: China
Material: High-grade Military Grade Materials
Copper Weight: 1-6oz
Layer Count: 2-30 Layers
Certifications: CE, ROHS
Impedance Control: ±10%
Attributes: High Reliability, EMI Resistance, Extreme Temperature Resistance
FAQ:
Q: What is the brand name of this product?
A: The brand name of this product is Military PCB.
Q: Where is the Military PCB product manufactured?
A: The Military PCB product is manufactured in China.
Q: What are the key features of the Military PCB product?
A: The key features of the Military PCB product include high durability, reliability, and performance.
Q: Is the Military PCB product suitable for military applications?
A: Yes, the Military PCB product is designed specifically for military applications, offering robust performance in demanding environments.
Q: Can the Military PCB product be customized according to specific requirements?
A: Yes, the Military PCB product can be customized to meet specific requirements, ensuring compatibility with various military systems.
