FR4 High Frequency PCB Printed Circuit Board 2-30 Layers Double Sided Customized
Product Details:
| Brand Name: | High Frequency PCB |
| Certification: | ISO 9001, CE,ROHS |
| Model Number: | Varies by goods condition |
Payment & Shipping Terms:
| Minimum Order Quantity: | Sample,1 pc(5 square meters) |
|---|---|
| Price: | NA |
| Delivery Time: | 14-15 Working Day |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 100000㎡/Month |
|
Detail Information |
|||
| Final Foil: | 1 Oz | Surface: | HASL-LF |
|---|---|---|---|
| Pcb Type: | Microwave RF Circuit Board | Certifications: | ISO 9001, CE,ROHS |
| Pcb Name: | Double Sided High Frequency PCB | Copper Weight: | Inner 1Oz;Outer 2oz |
| Min Via: | 0.1mm Laser Drill, 0.2mm Mechanic Drill | Quotation Request: | Gerber Files,BOM List |
| Highlight: | Customized FR4 High Frequency PCB,High Frequency Double Sided Fr4 Pcb,FR4 High Frequency Printed Circuit Board |
||
Product Description
Product Description:
A double-sided high-frequency PCB (Printed Circuit Board) is a specialized type of PCB designed for handling high-frequency signals and offering a two-layer configuration for more compact, high-performance designs. A double-sided PCB refers to a board where electronic components are placed on both the top and bottom sides, with electrical connections (traces) routed through the board using vias. High-frequency PCBs are designed to operate effectively at frequencies above 100 MHz, typically in the range of GHz for RF (radio frequency) applications.Applications:
1. Telecommunications & Networking
- 5G/6G Infrastructure:
- Base Stations: Antenna arrays (AAUs), massive MIMO modules (>64 antennas), beamforming circuits. Requires ultra-low-loss laminates (Dk 170°C) and CTE-matched materials.
- Electronic Warfare (EW):
- Jammers, SIGINT (Signals Intelligence) systems operating at 2–40 GHz. Critical impedance control (±5%) for pulse integrity.
3. Automotive Electronics
- ADAS & Autonomous Driving:
- 77/79 GHz mmWave radar PCBs (e.g., blind-spot detection). Low moisture absorption (<0.1%) for reliability.
- V2X Communication:
- 5.9 GHz DSRC (Dedicated Short-Range Communication) antennas. Uses PTFE-ceramic laminates for stable Df.
4. Medical & Scientific Instruments
- Diagnostic Imaging:
- MRI RF coils (1.5T/3T), terahertz spectroscopy PCBs. Minimizes signal loss (Df < 0.001) for accuracy.
- Therapeutic Devices:
- RF ablation (2.45 GHz), hyperthermia systems. Biocompatible surface finishes (e.g., ENIG) required.
5. High-Performance Computing & IoT
- Data Centers:
- 112 Gbps PAM4 SerDes modules, optical transceivers. Controlled impedance (85/90/100 Ω) for signal integrity.
- Millimeter-Wave IoT:
- Industrial sensors (60 GHz), short-range high-bandwidth links (e.g., WiGig).
Customization:
Product Customization Services for High Frequency PCB:
Brand Name: High Frequency PCB
Place Of Origin: China
Delivery Time: 15-20 Working Day
Payment Terms: T/T
Supply Ability: 1000㎡
Flammability: UL 94V-0
Pcb Name: Double Sided High Frequency PCB
Layers: 2-30
Certifications: ISO 9001, ROHS,CE
Pcb Type: Microwave RF Circuit Board
Product Attributes: High-Frequency Substrate Materials, Signal Integrity (SI), Ground Plane Optimization
