FR4 Material Through Hole Double Sided PCB Board For Medical Device
Product Details:
| Place of Origin: | China |
| Brand Name: | xingqiang |
| Certification: | ROHS, CE |
| Model Number: | KAZD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | NA |
| Delivery Time: | 7-10 work days |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 3000 |
|
Detail Information |
|||
| Solder Mask: | Green, Blue, Red, Black, White | Min. Hole Size: | 0.2mm |
|---|---|---|---|
| Silkscreen: | White, Black, Yellow | Max. Panel Size: | 300mm*300mm |
| Surface Finish: | HASL, ENIG, OSP | Min. Line Width/Spacing: | 0.1mm/0.1mm |
| Testing: | Flying Probe Test, X-Ray Inspection, AOI | Copper Thickness: | 1/2oz-3oz |
| Min. Panel Size: | 50mm*50mm | Thickness: | 0.2-6.0mm |
| Layer: | 2-8 | Material: | FR4 |
| Special Technology: | Blind And Buried Vias, Impedance Control, Gold Finger | Application: | Medical PCB |
| Highlight: | FR4 Material Double Sided PCB Board,Through Hole Double Sided PCB,FR4 PCB Board For Medical Device |
||
Product Description
FR4 Green Soldermask HASL Material SMT Multilayer PCB Board
Product Description
FR4 through-hole double-sided board PCB is a printed circuit board made of FR4 epoxy glass fiber substrate, featuring double-sided wiring and through-hole technology. The FR4 material provides a stable base with excellent mechanical and electrical insulation properties. Both sides of the board are equipped with conductive circuits, connected by metal-plated through-holes (vias) that enable electrical continuity between the two layers. It is designed to accommodate through-hole components (such as resistors, capacitors, and connectors) which are inserted into pre-drilled holes and soldered to the pads on both sides, making it suitable for small to medium complexity electronic circuits.
Core Characteristics
- FR4 substrate foundation: Utilizes FR4 material, known for its high strength, good heat resistance (operating temperature typically -55℃ to 130℃), and stable electrical insulation, ensuring structural and performance reliability.
- Double-sided wiring with through-holes: Two layers of conductive circuits connected by plated through-holes, enabling signal transmission between layers and supporting basic circuit integration.
- Through-hole component compatibility: Designed for through-hole mounting, with drilled holes and corresponding pads to secure and solder traditional through-hole components.
Main Advantages
- Cost-effectiveness: FR4 is an economical substrate material, and the double-sided through-hole design involves simpler manufacturing processes (compared to multi-layer or SMT-only boards), resulting in lower production costs, ideal for budget-sensitive projects.
- Ease of assembly and repair: Through-hole components are easier to manually insert, solder, and replace, facilitating assembly in small-scale production or repair scenarios, especially suitable for hobbyists, prototyping, or low-volume manufacturing.
- Mechanical robustness: Through-hole soldering creates strong mechanical bonds between components and the board, enhancing resistance to vibration and mechanical stress, making it suitable for industrial equipment or devices subject to physical impact.
- Versatility: Compatible with a wide range of traditional through-hole components, meeting the needs of various electronic applications such as power supplies, audio equipment, and basic control circuits.
