Custom Industrial Control Printed Circuit Board ENIG Process for Robot Controllers
Product Details:
| Place of Origin: | China |
| Brand Name: | xingqiang |
| Certification: | ISO 9001 / RoHS /UL / IATF 16949 (automotive) |
| Model Number: | As Per Customer's Model |
Payment & Shipping Terms:
| Minimum Order Quantity: | Sample,1 pc(5 square meters) |
|---|---|
| Price: | Based on Gerber Files |
| Packaging Details: | Carton Or As Per Customer's Request |
| Delivery Time: | NA |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 100000㎡/Month |
|
Detail Information |
|||
| PCB Name: | Industrial Control PCB | Surface Mount Capability: | Yes |
|---|---|---|---|
| Min. Hole Size: | 0.1mm | Min. Line Width/Spacing: | 3mil |
| Layers: | 1-30L | Board Thickness: | 0.2-5.0mm |
| Dimension: | Customized | Temperature Range: | -40℃~+125℃ |
| Testing: | Flying Probe Test | Surface Finish: | HASL, ENIG, OSP |
| Quotation: | Gerber Or BOM List | Ink Color: | Green,Red,White,Black,Blue,Yellow |
| Highlight: | Custom industrial control PCB ENIG process,Robot controller printed circuit board,Industrial PCB with ENIG coating |
||
Product Description
FR4 Gold Immersion Industrial Control PCB Board
An FR-4 substrate immersion gold industrial control PCB is a specialized rugged circuit board, featuring a gold-plated surface that delivers superior corrosion resistance, excellent electrical conductivity and long-term reliability. Built on heat-resistant FR-4 material, it withstands harsh industrial conditions like extreme temperatures, EMI and humidity, ensuring stable signal transmission for industrial automation devices such as PLCs and motor drives.
Performance-Oriented Characteristics
| Characteristic Category | Details |
| Operating Temp Range | -40℃ ~ 125℃ |
| Operating Temp Range | High and stable |
| Corrosion Resistance | Excellent, long service life |
| EMI Resistance | Enhanced via optimized layout |
| Solderability | Good wetting, reliable joints |
Why Choose Us?
✔ 30 Years Expertise in PCB Manufacturing
✔ ISO 9001, ROHS, UL and ISO /TS16949 Certified
✔ Support customized services
✔ Professional Engineering Support (DFM, impedance simulation)
✔ Global Shipping (DHL, FedEx, UPS) – Delivered to USA, Germany, UK, Japan, Australia, etc.
Ordering Information
1. Gerber files (RS-274X)
2. BOM (if PCBA needed)
3. Impedance requirements & stack-up (if available)
4.Test requirements (TDR, network analyzer, etc.)
We’ll reply within 24 hours with a free quote, DFM report, and material recommendation.
Customized Industrial PCB Production
I. Design Preparation
• Define Specs: Determine key requirements (layers, materials, environment).
• Layout & Files: Complete the circuit design and generate manufacturing files (Gerbers, BOM).
• DFM Review: Check the design for easy and cost-effective manufacturing.
• II. Bare Board Fabrication
• Layer Formation: Image, etch, and laminate copper layers to create the core board structure.
• Drill & Plate: Drill holes and plate them with copper to connect layers (vias).
• Finish: Apply Solder Mask (protection) and Surface Finish (for soldering).
• E-Test: Test the bare board for any shorts or opens.
• III. Assembly and Validation (PCBA)
• SMT: Print solder paste and use automated machines to place Surface Mount Components.
• Soldering: Use reflow ovens (SMT) or wave soldering (THT) to secure components.
• Protection: Apply Conformal Coating to protect the board from harsh elements (moisture, dust).
• FCT: Perform comprehensive Functional Testing to ensure the final product works correctly.
