Black Oil Spray Tin Double Panel PCB HASL Treatment Customized Panel Thickness
Product Details:
| Place of Origin: | China |
| Brand Name: | xingqiang |
| Certification: | ROHS, CE |
| Model Number: | Varies by goods condition |
Payment & Shipping Terms:
| Minimum Order Quantity: | Sample,1 pc(5 square meters) |
|---|---|
| Price: | NA |
| Delivery Time: | 7-10 work days |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 100000㎡/Month |
|
Detail Information |
|||
| PCB Type: | Double Panel PCB | Silkscreen Color: | White |
|---|---|---|---|
| Surface Treatment: | HASL | Silkscreen: | White |
| Material: | FR-4 | Boardthickness: | Customized |
| Production Files: | Gerber Or BOM | Pcb Standard: | IPC-A-610 E Class II-III |
| Layer Count: | 2/4/6/8/10L Or Tailored | Board Thick: | 136/1.2/1.0/0.8mm Or Customized |
| Highlight: | Black Oil Double Panel PCB,HASL Treatment Dual Sided PCB Board |
||
Product Description
Black oil spray tin double panel PCB:
Core Features of Double-Sided PCB (Black Mask & HASL)
| Category | Key Feature | Key Point |
|---|---|---|
| Structure | Layer Count | 2 layers (Top + Bottom) with PTH vias for interconnection. |
| Solder Mask | Color & Function | Black; insulates copper, prevents shorts, protects from environment. |
| Surface Finish | Type & Benefit | Hot Air Solder Leveling (HASL); cost-effective, good solderability. |
| Base Material | Substrate | FR-4 epoxy laminate; standard for general electronics. |
| Performance | Main Application Scope | Low-to-medium frequency; suitable for cost-sensitive, general-purpose devices. |
| Applications | Typical Products | Power supplies, LED drivers, small household appliances, industrial controls. |
Reliable soldering performance: The tin layers enable excellent solder wetting, reducing the risk of cold solder joints and allowing multiple rework soldering, facilitating mass assembly and post-maintenance.
Superior light-shielding and protection: The black solder mask effectively blocks light interference in sensitive circuits and isolates the board from external environments, enhancing corrosion and abrasion resistance.
Cost-effectiveness: The mature spray tin process combined with economical black ink and standard substrates results in controllable production costs, suitable for cost-sensitive fields like consumer electronics, home appliances, and industrial control.
Mechanical robustness: The tin layers form strong bonds with components during soldering, improving resistance to vibration and mechanical stress, making it suitable for devices subject to physical impact.
Good environmental adaptability: Maintains stable performance in normal temperature, humidity, and general dust conditions, ensuring consistent operation over extended periods.
