UL 94V-0 Flammability Microwave RF Circuit Board PCB For Signal Transmission OEM
Product Details:
| Brand Name: | High Frequency PCB |
| Certification: | ROHS, CE |
| Model Number: | Varies by goods condition |
Payment & Shipping Terms:
| Minimum Order Quantity: | Sample,1 pc(5 square meters) |
|---|---|
| Price: | N/A |
| Delivery Time: | 14-15 Working Day |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 100000㎡/Month |
|
Detail Information |
|||
| Pcb Type: | Microwave RF Circuit Board | Pcb Name: | Double Sided High Frequency PCB |
|---|---|---|---|
| Final Foil: | 1 Oz | Flammability: | Yes |
| Oem: | Custom | Smt Efficiency: | BGA |
| Min Via: | 0.1mm Laser Drill, 0.2mm Mechanic Drill | Min Line Space: | 3mil |
| Quotation Request: | Gerber Files,BOM | ||
| Highlight: | OEM Microwave RF Circuit Board,UL 94V-0 Flammability Microwave Circuit Board,Microwave PCB For Signal Transmission |
||
Product Description
Product Description:
The High Frequency PCB is a custom OEM product designed for applications requiring exceptional signal integrity and high-frequency signal transmission. This advanced PCB features a sleek grey color and surface finish with HASL-LF technology, ensuring superior quality and performance.
With a minimum line space of 3mil, this High Frequency PCB is optimized for ground plane optimization, a critical factor in maintaining signal integrity and reducing electromagnetic interference. The immersion gold finish (ENIG) further enhances the board's performance by providing excellent conductivity and corrosion resistance.Ground plane optimization is a key feature of this High Frequency PCB, as it helps to minimize signal distortion and ensure reliable high-frequency signal transmission. By providing a solid ground plane, this PCB is able to maintain signal integrity and reduce the impact of noise and crosstalk, resulting in a high-performance electronic system.
Features:
1.High Component Density: Accommodates more components (e.g., microchips, resistors) per unit area via fine-pitch technology, reducing overall board size.
2. Fine Line and Space (L/S): Features narrower conductive lines and smaller gaps between them, typically with L/S values below 0.1mm, enabling precise signal transmission.
3. Multi-Layer Configuration: Adopts more layers (often 8 layers or more) to optimize signal routing, isolate interference, and enhance integration.
4. Excellent Signal Integrity: Minimizes signal loss, crosstalk, and delay through advanced design and material selection, suitable for high-frequency applications.
5. High Reliability: Uses high-quality substrates and strict manufacturing processes to withstand harsh environments (e.g., temperature fluctuations, vibration) in industrial, automotive, and aerospace fields.
FAQ:
Q: What is the brand name of the high frequency PCB product?
A: The brand name of the high frequency PCB product is High Frequency PCB.
Q: Where is the high frequency PCB product manufactured?
A: The high frequency PCB product is manufactured in Dongguan,China.
Q: What Files are typically used to make circuit boards?
A: Circuit board manufacturing typically requires Gerber files and a Bill of Materials (BOM) to ensure accuracy during the production process.
Q: What are the payment terms for purchasing the high frequency PCB product?
A: The payment terms for purchasing the high frequency PCB product are T/T.
Q: What is the supply ability of the high frequency PCB product?
A: The supply ability of the high frequency PCB product is 200000㎡ per month.
