100 x 20 mm 6 Layer FR4 Multilayer PCB Board with High Mechanical Strength and Excellent Current Carrying Capacity
Product Details:
| Brand Name: | Xingqiang |
| Certification: | ROHS,ISO,UL,IATF |
| Model Number: | As Per Customer's Model |
Payment & Shipping Terms:
| Minimum Order Quantity: | Sample,1 Pc(5 Square Meters) |
|---|---|
| Price: | Based On Gerber Files |
| Packaging Details: | Carton Or As Your Request |
| Delivery Time: | NA |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 100000㎡/Month |
|
Detail Information |
|||
| Board Size: | 100 * 20 Mm | Solder Mast: | Customized |
|---|---|---|---|
| Surface Finish: | HASL, ENIG, OSP, Immersion Silver | Production: | Gerber File Or Design Data Needed. |
| Soldmask: | Green | Components Purchasing: | OK |
| Glass Epoxy: | RO4003C | Layers: | 4L |
Product Description
100 x 20 Mm Heavy Copper PCB 6 Layer PCB Board
Product Overview
This high-quality multilayer PCB board is designed to meet demanding electronic application requirements.
With board sizes of 100×20mm and 120×90mm options, it offers versatility and precision for various circuit designs.
Crafted from premium FR4 material, this PCB guarantees excellent mechanical strength, durability, and superior electrical performance.
The board features customizable thickness ranging from 0.4mm to 3.2mm, allowing engineers to tailor specifications
for compact devices or robust high-power electronics. This precise thickness control contributes to improved signal
integrity and enhanced reliability.
The green soldermask provides superior protection to copper traces while resisting oxidation and environmental damage.
This protective layer facilitates easier soldering during assembly, reducing manufacturing defects and improving production efficiency.
With impedance control testing capabilities, the board ensures signal consistency and minimizes signal loss or interference,
making it ideal for high-frequency and high-speed applications. The multilayer design supports complex circuit architectures
while maintaining excellent electrical isolation between layers.
Technical Specifications
| Parameter | Specification |
|---|---|
| Surface Finish | HASL, ENIG, OSP, Immersion Silver |
| Production | Gerber File Or Design Data Needed |
| Glass Epoxy | RO4003C |
| Size | 120mm × 90mm |
| Board Thickness | 0.4mm To 3.2mm |
| Soldermask | Green |
| RoHS Compliant | Yes |
| Layers | 4L |
| Board Size | 100mm × 20mm |
| Samples | Available |
Applications
This versatile multilayer PCB board meets rigorous demands across various electronic applications.
Certified with ROHS, ISO, UL, and IATF standards, it ensures top-notch quality and reliability for both
prototype and mass production needs.
Ideal applications include:
- Telecommunications equipment
- Automotive electronics
- Medical devices
- Aerospace systems
- Industrial control systems
- Consumer electronics
With a supply capacity of 100,000 square meters per month and flexible packaging options,
this PCB board supports seamless production workflows for both small-scale projects and high-volume manufacturing.
Frequently Asked Questions
What brand manufactures the Multilayer PCB Board?
The Multilayer PCB Board is manufactured by Xingqiang, a trusted brand from China.
Can I order a sample or just one piece of the Multilayer PCB Board?
Yes, the minimum order quantity is as low as 1 piece or a sample, covering 5 square meters.
What certifications does the Multilayer PCB Board have?
The product is certified with ROHS, ISO, UL, and IATF standards.
How is the price of the Multilayer PCB Board determined?
The price is based on the Gerber files you provide for your specific design.
What are the payment terms available for purchasing the Multilayer PCB Board?
We accept payment via T/T and Western Union.
What is the packaging method for the Multilayer PCB Board?
The boards are packaged in cartons or according to your specific request.
What is the monthly supply capacity for the Multilayer PCB Board?
We have a supply ability of up to 100,000 square meters per month.
