• 8 Layer Green Solder Mask HDI PCB 1.6mm Thickness Industrial Control PCB Board
8 Layer Green Solder Mask HDI PCB 1.6mm Thickness Industrial Control PCB Board

8 Layer Green Solder Mask HDI PCB 1.6mm Thickness Industrial Control PCB Board

Product Details:

Brand Name: Xingqiang
Certification: ROHS, CE
Model Number: Varies by goods condition

Payment & Shipping Terms:

Minimum Order Quantity: 5 square meters
Price: NA
Delivery Time: 14-15 work days
Payment Terms: ,T/T,Western Union
Supply Ability: 3000㎡
Get Best Price Chat Now

Detail Information

UL Certification: Yes Silkscreen Color: White
Thickness: 1.6mm Layer: 2
Min. Hole Size: 0.1mm Base Material: FR4
Suface Finish: HASL Internal Model: C654004C16
Highlight:

Green Solder Mask HDI PCB

,

1.6mm Thickness Industrial Control PCB

,

8 Layer Industrial Control PCB Board

Product Description

Product Description

  An 8-layer HDI (High-Density Interconnect) industrial control board PCB is a specialized circuit board designed for use in demanding industrial environments. It's a multi-layered board with eight distinct layers, utilizing HDI technology to achieve a higher density of components and finer circuit lines. This type of board is the core component in industrial machinery and control systems, where reliability, durability, and high performance are non-negotiable.

Key Features and Characteristics

  • 8-Layer Stack-up: This configuration allows for complex routing and effective separation of power, ground, and signal layers, which is crucial for signal integrity and noise reduction in industrial settings.

  • High-Density Interconnect (HDI) Technology: The use of microvias, buried vias, and blind vias enables a much higher component density than a conventional board. This results in a smaller, more compact design without sacrificing functionality.

  • Robust Materials: Industrial control boards are built to withstand harsh conditions. They use durable materials that can handle mechanical stress, temperature fluctuations, and exposure to dust, chemicals, and vibration.

  • Signal Integrity: The multi-layer design, combined with HDI technology, ensures excellent signal integrity. This is vital for high-speed digital signals, preventing data loss and communication errors in complex control systems.

  • Thermal Management: The board's design often includes features for efficient heat dissipation, which is critical for components operating under high power in enclosed spaces.

Main Applications

  • Factory Automation: They are the "brains" of automated assembly lines, robotic arms, and CNC machines, controlling every movement and process.

  • Motor Control Systems: Used in variable frequency drives (VFDs) and other motor controllers to precisely manage the speed and torque of industrial motors.

  • Power and Energy Systems: Found in power distribution units, smart grid technology, and other energy management devices.

  • Heavy Machinery: Integrated into construction equipment, agricultural machinery, and other heavy-duty vehicles to manage their electronic systems.

Want to Know more details about this product
I am interested in 8 Layer Green Solder Mask HDI PCB 1.6mm Thickness Industrial Control PCB Board could you send me more details such as type, size, quantity, material, etc.
