Custom High Precision Flexible Printed Circuit FPC Board Panelized for Mass Production
Brand Name:
Xingqiang
Certification:
ISO 9001 / ROHS /UL / IATF 16949 (automotive)
Model Number:
As Per Customer's Model
Minimum Order Quantity:
Sample,1 Pc(5 Square Meters)
Price:
Based On Gerber
Standard Packaging:
As Per Customer's Request
Delivery Time:
NA
Payment Terms:
,T/T,Western Union
Supply Ability:
100000㎡/Month
Product Details
Highlight:
custom flexible printed circuit board
,high precision FPC panel
,mass production double sided PCB
Product Name:
Custom Double-sided PCB
IPC Class 2:
Yes
Cu Thickness:
1/1oz
Silkscreen Color:
White
Copper Overall:
0.5-5oz
Routing:
+/-0.1mm
Quotation:
Gerber Files
Layer Counts:
1-30 Layers
Supplier Type:
OEM/ODM/PCBA
Hole Size Tolerance:
PTH ±0.075, NTPH ±0.05
Pcb Board Thickness:
1.6/1.2/1.0/0.8/0.6/0.4/0.2MM
Solder Mask:
Green,Red,White,Yelllow,Blue,Black
Product Description
Product Description:
Xingqiang Circuit Board Co., Ltd. (Dongguan Xingqiang) is a veteran manufacturer of high-precision, high-density PCBs. The item pictured is a custom Flexible Printed Circuit (FPC) from our company.Made of polyimide (PI) flexible substrate via precision etching, this FPC comes in a 2×5 array panel with 10 units per board. It withstands frequent dynamic bending, fits complex 3D spaces, and replaces traditional wiring to save device space. With fine circuit lines, neat pads, and excellent temperature/fatigue resistance, it guarantees reliable soldering and stable signal transmission, supports automated SMT assembly for higher mass production efficiency, and is ideal for consumer electronics, automotive electronics, medical devices, home appliances and other flexible connection applications.
Main Advantages:
Flexibility & Bendability: Capable of withstanding high-cycle dynamic flexing, compatible with complex 3D mechanical packaging, and enables wire harness reduction for significant space savings in end products.High-Precision Fabrication: Utilizes precision etching processes and optimized pad geometries, ensuring high soldering yields and consistent signal integrity.
Panelized for Mass Production: Multi-up panel design enhances manufacturing throughput, with standardized part numbering for simplified SMT processing and supply chain control.
Application-Specific Customization: circuit routing engineered to the end product's mechanical envelope, ensuring seamless fit in confined installation areas.
Superior Reliability: Temperature-stable polyimide substrate, robust copper foil adhesion, and excellent mechanical robustness against vibration and flex fatigue, guaranteeing long-term operational reliability.
Custom FPC Production Flow:
Design Review → Material Prep → Exposure & Etching → Surface Treatment → Coverlay Lamination → Forming → Electrical Testing → Quality Inspection → Finished Panel Delivery
