Customizable Black Oil Dual Sided PCB Meet Rigorous Electronic Assembly Standards
Product Details:
| Brand Name: | Xingqiang |
| Certification: | ISO 9001 / ROHS /UL / IATF 16949 (automotive) |
| Model Number: | As Per Customer's Model |
Payment & Shipping Terms:
| Minimum Order Quantity: | Sample,1 Pc(5 Square Meters) |
|---|---|
| Price: | Based On Gerber |
| Packaging Details: | As Per Customer's Request |
| Delivery Time: | NA |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 100000㎡/Month |
|
Detail Information |
|||
| Product Name: | Custom Dual Sided PCB | Reinforcement: | FR4 |
|---|---|---|---|
| Min Hole Size: | 0.1Mm | Copper Overall: | 0.5-5oz |
| Mini Line Width: | 0.076mm | Quality Standard: | IPC Class II |
| PTH: | +/-0.075mm | Layer: | 1~30 Layers |
| Max Board Size: | 528*600Mm | Pcb Board Thickness: | 2.0mm/1.6mm/1.2mm/1.0mm/0.8mm/0.6mm/0.4mm |
| Highlight: | customizable black oil double sided PCB,dual sided PCB for electronic assembly,rigorous standard double sided PCB |
||
Product Description
What is Double Sided PCB:
The Double Sided PCB, also known as a Double Sided PC Board or Dual Sided PCB, is a highly versatile and widely used printed circuit board designed to accommodate complex electronic circuits with enhanced functionality and efficiency. This type of PCB features conductive copper layers on both the top and bottom sides, allowing for increased circuit density and more compact designs compared to single-sided PCBs. The Double Sided Panel design is particularly beneficial for applications requiring intricate routing and higher component placement flexibility, making it an ideal choice for a broad range of electronic devices.
Technical Parameters:
| PCB Name | Custom Double Sided PCB |
| Surface Treatment | ENIG or Customized |
| Mini Line Width | 0.076mm |
| PCB Board Thickness | 1.6mm / On Your Request |
| Layer | 1~20 Layers, 1-30 Layer |
| Min Hole Size | 0.1mm |
| High-Tg FR-4 | -20°C to +105°C |
| FOB Price | Based on Gerber Files |
Customization Service Support:
Xingqiang offers high-quality Double Sided PC Board customization services tailored to your specifications. Our Dual Sided PCB products are manufactured as per the customer's model, ensuring precise adherence to your design requirements. Originating from China, our PCBs come with certifications including ISO 9001, ROHS, UL, and IATF 16949 (automotive), guaranteeing reliability and industry compliance.
FAQ:
1.What is this PCB and its main use?
This is a custom wireless charging coil PCB from Xingqiang PCB Technology, used in consumer electronics, smart wearables, and desktop chargers for contactless power transfer.
2. Can you customize this PCB for my project?
Yes, we offer full customization including coil parameters, dimensions, materials, and component integration to meet your specific needs.
3. What services does Xingqiang provide?
We provide customizable solutions, rapid prototyping, mass production, strict quality testing, and global shipping with after-sales support.
4. What certifications do these PCBs have?
Our products are RoHS & REACH compliant and ISO 9001 certified. Optional certifications like IATF16949 (automotive) and ISO13485 (medical) are available on request.
