Custom Double-Sided Printed Circuit Board High Thermal Conductivity for Medical Devices
Product Details:
| Brand Name: | Xingqiang |
| Certification: | ISO 9001 / ROHS /UL / IATF 16949 (automotive) |
| Model Number: | As Per Customer's Model |
Payment & Shipping Terms:
| Minimum Order Quantity: | Sample,1 Pc(5 Square Meters) |
|---|---|
| Price: | Based On Gerber |
| Packaging Details: | Carton box |
| Delivery Time: | NA |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 100000㎡/Month |
|
Detail Information |
|||
| Product Name: | Custom Double-Sided PCB | Surface Finish: | HASL (Lead Free) |
|---|---|---|---|
| Board Size: | Customized | Characteristic Service: | ODM/OEM/PCBA |
| SMT Technology: | SMD, BGA, QFN | Profiling Punching: | Routing, V-CUT, Beveling |
| Quotation Files: | Gerber Files Or BOM(PCBA) | Pcb Board Thickness: | 1.6mm/1.2mm/1.0mm/0.8mm Or Tailored |
| Application: | Medical Devices,Consumer Electronics, Industrial Equipment | Normal Layer Count: | 2-Layers,4-Layers/6-Layers/8-Layers/10-Layers |
| Highlight: | Custom double-sided PCB for medical devices,High thermal conductivity double-sided PCB,Printed circuit board with medical applications |
||
Product Description
Custom Medical Double-Sided PCB High-Reliability FR-4 Circuit Board:
This is a high-reliability double-sided 2-layer PCB board designed for medical applications. Built with FR‑4 high-Tg material, it features metalized vias, precise wiring, and supports ENIG/immersion gold surface finish. Fully customizable in thickness, copper weight, hole size, and outline; supports OEM/ODM, strict impedance control, and clean-room production. RoHS, ISO compliant, with high stability, anti-corrosion, and long service life. Ideal for diagnostic, patient monitoring, surgical, and wearable medical devices.
Main Features:
• High reliability, stability, long service life and good anti-corrosion performance
• High-Tg FR‑4 material with excellent heat resistance
• ENIG/immersion gold finish ensures reliable soldering and stable signal transmission
• Fully customizable specifications with strict impedance control
• ISO & RoHS compliant, manufactured in clean room for medical applications
Technical Parameters:
| PCB Type | Double-Sided PCB |
| Solder Mask Color | Green or Customized |
| Surface Finish | HASL (Lead Free)/ENIG/OSP |
| Board Size | As your request |
| PCB Board Thickness | 1.6mm/1.2mm/1.0mm/0.8mm/0.2mm |
| Material | FR4 |
| Characteristic Service | ODM/OEM/PCBA |
| Layer Count | 1-30 Layers |
| Profiling Punching | Routing, V-CUT, Beveling |
What documents are required for custom PCB fabrication?:
Please send your:
1.Gerber files
Standard PCB layout data for manufacturing (copper layers, solder mask, silkscreen, drills).
2. BOM (Bill of Materials)
List of components with part numbers, description, quantity, package, and manufacturer.
3. Pick-and-place file (Centroid file)
Coordinates and rotation data for automated component assembly.
4. Schematic file
Circuit diagram for design verification (PDF or source file).
5. PCB fabrication notes
Specifications: board material, thickness, copper weight, surface finish, solder mask color, quantity.
6. Mechanical drawing
Outline, mounting holes, keep-out areas, and dimension requirements.
7. Test requirements
ICT, AOI, functional test, or other inspection standards.
